Fiber Optics

Fiber optics features minimal light loss and total internal reflection (TIR), which allows them to potentially be very long (hundreds of kilometers) and flexible.

Product	Wavelength Range	Cut-Off Wavelength	Mode Field Diameter	Availability	Price (USD)
Universal Fiber Coupler	350 - 3000 nm	-	-	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 350 - 3000 nm Dimensions 40 x 40 x 41.5 mm Fiber Connector Type FC/APC, FC/PC Fiber Type PM Fiber, SM Fiber Port Configuration 1x2 Clear Aperture < 6 mm > 4.5 mm (Typical) Number of Channels 1, 2 Fiber Coupling Loss -1.249 dB Supplier Location Germany See product details More from Toptica
High Power Patch Cable	395 - 500 nm	< 395 nm	3.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 395 - 500 nm Cut-Off Wavelength < 395 nm Mode Field Diameter 3.5 μm Dimensions 2000 mm (Length) Fiber Connector Type FC/AFC Numerical Aperture 0.07 Fiber Cable Length 2 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Fiber Collimator	350 - 3000 nm	-	-	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 350 - 3000 nm Dimensions 20 x 20 x 34.5 mm Fiber Connector Type FC/APC, FC/PC Fiber Type PM Fiber, SM Fiber Clear Aperture 4.5 mm (Typical) Output Waist Diameter (1/e²) 0.6 - 3.5 mm (Typical Beam Sizes out of SM-fiber) Supplier Location Germany See product details More from Toptica
Polarization Maintaining Fiber Optic Couplers	680 - 880 nm 750 - 950 nm 835 - 1035 nm 880 - 1080 nm 930 - 1130 nm 964 - 1164 nm 1060 - 1260 nm 1210 - 1410 nm 1290 - 1490 nm 1450 - 1650 nm	-	-	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 680 - 880 nm 750 - 950 nm 835 - 1035 nm 880 - 1080 nm 930 - 1130 nm 964 - 1164 nm 1060 - 1260 nm 1210 - 1410 nm 1290 - 1490 nm 1450 - 1650 nm Dimensions 23 x 90 x 200 mm Fiber Connector Type FC/APC Fiber Type PM Fiber Port Configuration 1x2 Number of Channels 1, 2 Applications Interferometry Quantum Computing Spectroscopy Coupling Ratio 90:10, 70:30, 50:50 Wavelength Bandwidth (FWHM) 100 nm Connector Style 1. Frequency comb + cw laser: fiber-coupled (FC/APC Fiber for beat-light output included) 2. cw laser: fiber-coupled (FC/APC) (Output), 1. Frequency Comb: fiber-coupled (FC/APC Fiber for comb-light input included) 2. cw laser: fiber-coupled (FC/APC) (Input) Center Wavelength 780 nm, 850 nm, 935 nm, 980 nm, 1030 nm, 1064 nm, 1160 nm, 1310 nm, 1390 nm, 1550 nm (others on Request) Supplier Location Germany See product details More from Toptica
High Power Patch Cable	620 - 780 nm	< 620 nm	4.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 620 - 780 nm Cut-Off Wavelength < 620 nm Mode Field Diameter 4.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/AFC Numerical Aperture 0.1 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
High Power Patch Cable	760 - 980 nm	< 760 nm	5.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 760 - 980 nm Cut-Off Wavelength < 760 nm Mode Field Diameter 5.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/AFC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	1460 - 1620 nm	< 1460 nm	10.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 1460 - 1620 nm Cut-Off Wavelength < 1460 nm Mode Field Diameter 10.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.09 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
High Power Patch Cable	460 - 640 nm	< 450 nm	4 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 460 - 640 nm Cut-Off Wavelength < 450 nm Mode Field Diameter 4 μm Dimensions 2000 mm (Length) Fiber Connector Type FC/AFC Numerical Aperture 0.08 Fiber Cable Length 2 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	480 - 630 nm	< 470 nm	3.8 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 480 - 630 nm Cut-Off Wavelength < 470 nm Mode Field Diameter 3.8 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
High Power Patch Cable	940 - 1300 nm	< 930 nm	6.6 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 940 - 1300 nm Cut-Off Wavelength < 930 nm Mode Field Diameter 6.6 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/AFC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
High Power Patch Cable	375 - 488 nm	< 370 nm	3.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 375 - 488 nm Cut-Off Wavelength < 370 nm Mode Field Diameter 3.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/AFC Numerical Aperture 0.07 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	405 - 480 nm	< 400 nm	3.8 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 405 - 480 nm Cut-Off Wavelength < 400 nm Mode Field Diameter 3.8 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
High Power Patch Cable	1290 - 1550 nm	< 1280 nm	9 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 1290 - 1550 nm Cut-Off Wavelength < 1280 nm Mode Field Diameter 9 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/AFC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	630 - 820 nm	< 620 nm	4.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 630 - 820 nm Cut-Off Wavelength < 620 nm Mode Field Diameter 4.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	350 - 440 nm	< 340 nm	2.3 - 2.6 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 350 - 440 nm Cut-Off Wavelength < 340 nm Mode Field Diameter 2.3 - 2.6 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.12 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	980 - 1300 nm	< 970 nm	6.6 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 980 - 1300 nm Cut-Off Wavelength < 970 nm Mode Field Diameter 6.6 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	1290 - 1550 nm	< 1280 nm	9.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 1290 - 1550 nm Cut-Off Wavelength < 1280 nm Mode Field Diameter 9.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	760 - 850 nm	< 760 nm	5.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 760 - 850 nm Cut-Off Wavelength < 760 nm Mode Field Diameter 5.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/AFC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	1460 - 1625 nm	< 1450 nm	10.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 1460 - 1625 nm Cut-Off Wavelength < 1450 nm Mode Field Diameter 10.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
Polarization-Maintaining Patch Cable	760 - 980 nm	< 760 nm	5.5 μm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 760 - 980 nm Cut-Off Wavelength < 760 nm Mode Field Diameter 5.5 μm Dimensions 3000 mm (Length) Fiber Connector Type FC/APC Numerical Aperture 0.11 Fiber Cable Length 3 m Fiber Jacket Outer Diameter 3 mm Supplier Location Germany See product details More from Toptica
