Reflective optical components that feature a flat surface and are commonly used to steer beams without introducing chromatic aberration and minimize dispersion.

Product	Wavelength Range	Reflectance	Substrate	Availability	Price (USD)
Rectangular Mirror	-	> 90%	BK7	2 weeks	$ 74.00
Product Code Coating Protected Aluminum Reflectance > 90% Dimensions 10 x 15 mm Thickness 5 mm Parallelism < 3' Substrate BK7 Surface Irregularity λ/20 (Flatness) Surface Quality 40-20 scratch-dig Damage Threshold Pulsed 0.25 J/cm² Shape Rectangular Angle of Incidence 45° Weight 5 g Rear Surface Ground Supplier Location California, USA See product details More from OptoSigma
Rectangular Mirror	-	> 90%	BK7	2 - 3 weeks	$ 42.00
Product Code Coating Protected Aluminum Reflectance > 90% Dimensions 20 x 30 mm Thickness 5 mm Parallelism < 3' Substrate BK7 Surface Irregularity λ (Flatness) Surface Quality 40-20 scratch-dig Damage Threshold Pulsed 0.25 J/cm² Shape Rectangular Angle of Incidence 45° Weight 8 g Rear Surface Ground Supplier Location California, USA See product details More from OptoSigma
Rectangular Mirror	-	> 90%	BK7	6 - 12 weeks	$ 37.00
Product Code Coating Protected Aluminum Reflectance > 90% Dimensions 25 x 35 mm Thickness 5 mm Parallelism < 3' Substrate BK7 Surface Irregularity λ/10 (Flatness) Surface Quality 60-40 scratch-dig Damage Threshold Pulsed 0.25 J/cm² (10 ns, 20 Hz) Shape Rectangular Angle of Incidence 45° Weight 12 g Rear Surface Ground Supplier Location California, USA See product details More from OptoSigma
Rectangular Mirror	351 - 358 nm	> 99.5% (351 - 358 nm, Average) > 99.8% (355 nm, Absolute)	Fused Silica	In stock	$ 94.34
Product Code Wavelength Range 351 - 358 nm Center Wavelength 355 nm Coating Dielectric Reflectance > 99.5% (351 - 358 nm, Average) > 99.8% (355 nm, Absolute) Dimensions 9.53 x 6.35 mm (+0/-0.1 mm) Thickness 3.18 mm Parallelism < 3' Substrate Fused Silica Surface Irregularity λ/10 (PV, Flatness) Surface Quality 10-5 scratch-dig Damage Threshold Pulsed 6 J/cm² (20 ns, 20 Hz, 355 nm) Shape Rectangular Angle of Incidence 45° Clear Aperture 8.1005 x 5.3975 mm Thickness Tolerance ±0.2 mm Laser Type Nd:YAG Supplier Location New Jersey, USA See product details More from Edmund Optics
Rectangular Mirror	1020 - 1040 nm	> 99.5% (1020 - 1040 nm, Average) > 99.8% (1030 nm, Absolute)	Fused Silica	In stock	$ 155.82
Product Code Wavelength Range 1020 - 1040 nm Center Wavelength 1030 nm Coating Dielectric Reflectance > 99.5% (1020 - 1040 nm, Average) > 99.8% (1030 nm, Absolute) Dimensions 19.1 x 12.7 mm (+0/-0.1 mm) Thickness 6.35 mm (0.25") Parallelism < 3' Substrate Fused Silica Surface Irregularity λ/10 (PV, Flatness) Surface Quality 10-5 scratch-dig Damage Threshold Pulsed 20 J/cm² (20 ns, 20 Hz, 1030 nm) Shape Rectangular Angle of Incidence 45° Clear Aperture 16.24 x 10.795 mm Thickness Tolerance ±0.2 mm Laser Type Yb:YAG Supplier Location New Jersey, USA See product details More from Edmund Optics
Rectangular Mirror	600 - 1000 nm	-	Fused Silica	In stock	$ 292.16
Product Code Wavelength Range 600 - 1000 nm Center Wavelength 600 - 1000 nm Reflection Wavelength 600 - 1000 nm Coating Protected Silver Dimensions 40 x 30 mm Thickness 6.35 mm (0.25") Parallelism 5' Substrate Fused Silica Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Surface Quality 10-5 scratch-dig 5/2x0.063; L1x0.004 (Front) (ISO-7) Shape Rectangular Angle of Incidence 0 - 45° Thickness Tolerance ±0.1 mm Laser Type Ti:Sa Chamfer 0.3 mm (Rear) 0.3 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Rectangular Mirror	450 - 650 nm	> 95% (45°, 450 - 650 nm, Average)	Float Glass	In stock	$ 52.47
Product Code Wavelength Range 450 - 650 nm Coating UV-Enhanced Aluminum Reflectance > 95% (45°, 450 - 650 nm, Average) Dimensions 60 x 85 mm Thickness 3 mm Substrate Float Glass Surface Irregularity 4 - 6λ (PV, Flatness) Surface Quality 60-40 scratch-dig Damage Threshold Pulsed 0.2 J/cm² (10 ns, 532 nm) Shape Rectangular Clear Aperture 57 x 80.75 mm Length 85 mm Width 60 mm Supplier Location New Jersey, USA See product details More from Edmund Optics
Rectangular Mirror	-	> 90%	BK7	6 - 12 weeks	$ 53.00
Product Code Coating Aluminum Reflectance > 90% Dimensions 15 x 25 mm Thickness 5 mm Parallelism < 3' Substrate BK7 Surface Irregularity λ/10 (Flatness) Surface Quality 40-20 scratch-dig Damage Threshold Pulsed 0.25 J/cm² Shape Rectangular Angle of Incidence 45° Weight 5 g Rear Surface Ground Supplier Location California, USA See product details More from OptoSigma
Rectangular Mirror	700 - 10000 nm	> 96% (2000 - 10000 nm, Average)	Float Glass	Contact Supplier	$ 80.03
Product Code Wavelength Range 700 - 10000 nm Coating Protected Gold Reflectance > 96% (2000 - 10000 nm, Average) Dimensions 35 x 50 mm Thickness 3 mm Substrate Float Glass Surface Irregularity 4 - 6λ (PV, Flatness) Surface Quality 60-40 scratch-dig Damage Threshold Pulsed 0.8 J/cm² (10 ns, 1064 nm) Shape Rectangular Clear Aperture 33.25 x 47.5 mm Length 50 mm Width 35 mm Supplier Location New Jersey, USA See product details More from Edmund Optics
Rectangular Mirror	450 - 650 nm	> 95% (45°, 450 - 650 nm, Average)	Float Glass	In stock	$ 27.03
Product Code Wavelength Range 450 - 650 nm Coating UV-Enhanced Aluminum Reflectance > 95% (45°, 450 - 650 nm, Average) Dimensions 8 x 11.5 mm Thickness 2 mm Substrate Float Glass Surface Irregularity 4 - 6λ (PV, Flatness) Surface Quality 60-40 scratch-dig Damage Threshold Pulsed 0.2 J/cm² (10 ns, 532 nm) Shape Rectangular Clear Aperture 7.2 x 10.35 mm Length 8 mm Width 11.5 mm Supplier Location New Jersey, USA See product details More from Edmund Optics
Rectangular Mirror	400 - 700 nm	> 85% (400 - 700 nm, Average)	Float Glass	In stock	$ 21.20
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Dimensions 22 x 29 mm (±0.76 mm) Thickness 1.6 mm Substrate Float Glass Surface Irregularity 4 - 6λ (Flatness) Surface Quality 80-50 scratch-dig Shape Rectangular Angle of Incidence 45° Clear Aperture > 19.8 x 26.1 mm Length 29 mm Width 22 mm Bevels Protective as needed Supplier Location New Jersey, USA See product details More from Edmund Optics
Chirped Mirror Pair	510 - 920 nm 520 - 900 nm	> 99.7% (5°, 510 - 920 nm, Front)	Fused Silica	In stock	$ 2031.53
Product Code Wavelength Range 510 - 920 nm 520 - 900 nm Center Wavelength 510 - 920 nm 520 - 900 nm Reflection Wavelength 510 - 920 nm Coating BBHR (510 - 920 nm) Reflectance > 99.7% (5°, 510 - 920 nm, Front) Dimensions 40 x 10 mm Thickness 12.5 mm Substrate Fused Silica Surface Irregularity λ/10 (546.1 nm, Front) Surface Quality 10-5 scratch-dig 5/3x0.04; L1x0.004 (Front) (ISO-7) Shape Rectangular Angle of Incidence 5° Thickness Tolerance ±0.1 mm Laser Type Ti:Sa Coating Features Broadband, Chirped Group Delay Dispersion -40 fs² (520 - 900 nm) Chamfer 0.4 mm (Front) 0.4 mm (Rear) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Chirped Mirror Pair	470 - 810 nm	> 99.7% (0°, 470 - 810 nm, Front)	Fused Silica	In stock	$ 2031.53
Product Code Wavelength Range 470 - 810 nm Center Wavelength 470 - 810 nm Reflection Wavelength 470 - 810 nm Coating BBHR (470 - 810 nm) Reflectance > 99.7% (0°, 470 - 810 nm, Front) Dimensions 40 x 10 mm Thickness 12.5 mm Substrate Fused Silica Surface Irregularity λ/10 (546.1 nm, Front) Surface Quality 10-5 scratch-dig 5/3x0.04; L1x0.004 (Front) (ISO-7) Shape Rectangular Angle of Incidence 0° Thickness Tolerance ±0.1 mm Laser Type Ti:Sa Coating Features Broadband, Chirped Group Delay Dispersion -40 fs² (470 - 810 nm) Chamfer 0.4 mm (Front) 0.4 mm (Rear) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Rectangular Mirror	-	> 90%	BK7	2 weeks	$ 37.00
Product Code Coating Protected Aluminum Reflectance > 90% Dimensions 10 x 15 mm Thickness 3 mm Parallelism < 3' Substrate BK7 Surface Irregularity λ/10 (Flatness) Surface Quality 40-20 scratch-dig Damage Threshold Pulsed 0.25 J/cm² Shape Rectangular Angle of Incidence 45° Weight 5 g Rear Surface Ground Supplier Location California, USA See product details More from OptoSigma
Rectangular Mirror	450 - 650 nm	> 95% (450 - 650 nm, Average)	Borofloat	Contact Supplier	$ 61.48
Product Code Wavelength Range 450 - 650 nm Coating UV-Enhanced Aluminum Reflectance > 95% (450 - 650 nm, Average) Dimensions 21 x 30 mm Thickness 5 mm Substrate Borofloat Surface Irregularity λ/4 (Flatness) Surface Quality 60-40 scratch-dig Damage Threshold Pulsed 0.2 J/cm² (10 ns, 532 nm) Shape Rectangular Clear Aperture 17.85 x 25.5 mm Thickness Tolerance +0.5/-0 mm Length 30 mm Width 21 mm Supplier Location New Jersey, USA See product details More from Edmund Optics
Rectangular Mirror	400 - 2000 nm	96% (400 nm)	UV Fused Silica	4 - 5 days	$ 55.00
Product Code Wavelength Range 400 - 2000 nm Reflection Wavelength 400 nm Coating Protected Silver Reflectance 96% (400 nm) Dimensions 15 x 20 mm Thickness 6 mm Substrate UV Fused Silica Surface Irregularity λ/10 (633 nm) Surface Quality 40-20 scratch-dig (S1) Damage Threshold Pulsed 1.8 J/cm² (50 Hz, 11 ns, 1064 nm) 0.25 J/cm² (50 Hz, 94 fs, 800 nm) Shape Rectangular Clear Aperture > 13.5 x 18 mm Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.13 mm Supplier Location Lithuania See product details More from EKSMA Optics
Rectangular Mirror	1020 - 1040 nm	> 99.5% (1020 - 1040 nm, Average) > 99.8% (1030 nm, Absolute)	Fused Silica	In stock	$ 143.10
Product Code Wavelength Range 1020 - 1040 nm Center Wavelength 1030 nm Coating Dielectric Reflectance > 99.5% (1020 - 1040 nm, Average) > 99.8% (1030 nm, Absolute) Dimensions 9.53 x 6.35 mm (+0/-0.1 mm) Thickness 3.18 mm Parallelism < 3' Substrate Fused Silica Surface Irregularity λ/10 (PV, Flatness) Surface Quality 10-5 scratch-dig Damage Threshold Pulsed 20 J/cm² (20 ns, 20 Hz, 1030 nm) Shape Rectangular Angle of Incidence 45° Clear Aperture 8.1005 x 5.3975 mm Thickness Tolerance ±0.2 mm Laser Type Yb:YAG Supplier Location New Jersey, USA See product details More from Edmund Optics
Chirped Mirror Pair	725 - 875 nm	> 99.8% (725 - 875 nm, 0 - 10°, Front) (s-pol) > 99.8% (725 - 875 nm, 0 - 10°, Front) (p-pol)	Fused Silica	Contact Supplier	$ 1891.11
Product Code Wavelength Range 725 - 875 nm Center Wavelength 725 - 875 nm Coating BBHR (725 - 875 nm) Reflectance > 99.8% (725 - 875 nm, 0 - 10°, Front) (s-pol) > 99.8% (725 - 875 nm, 0 - 10°, Front) (p-pol) Dimensions 40 x 10 mm Thickness 12.5 mm Parallelism 5' Substrate Fused Silica Surface Irregularity λ/10 (546.1 nm, Front) Surface Quality 10-5 scratch-dig 5/3x0.04; L1x0.004 (Front) (ISO-7) Shape Rectangular Angle of Incidence 0 - 10° Thickness Tolerance ±0.1 mm Laser Type Ti:Sa Coating Features Broadband, Chirped Group Delay Dispersion -40 fs² (725 - 875 nm, p-pol) Chamfer 0.4 mm (Rear) 0.4 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Rectangular Mirror	-	> 90%	-	In stock	$ 147.00
Product Code Coating Protected Aluminum Reflectance > 90% Dimensions 30 x 40 mm Thickness 6 mm Parallelism < 3' Surface Irregularity λ/10 (Flatness) Surface Quality 40-20 scratch-dig Damage Threshold Pulsed 0.25 J/cm² Shape Rectangular Angle of Incidence 45° Weight 16 g Rear Surface Polished Supplier Location California, USA See product details More from OptoSigma
Rectangular Mirror	-	> 90%	BK7	2 weeks	$ 37.00
Product Code Coating Aluminum Reflectance > 90% Dimensions 10 x 15 mm Thickness 3 mm Parallelism < 3' Substrate BK7 Surface Irregularity λ/10 (Flatness) Surface Quality 40-20 scratch-dig Damage Threshold Pulsed 0.25 J/cm² Shape Rectangular Angle of Incidence 45° Weight 5 g Rear Surface Ground Supplier Location California, USA See product details More from OptoSigma
