Ellipsoidal Mirrors

Mirrors that feature an ellipsoidal surface and two focal points. Due to this feature, ellipsoidal mirrors can efficiently refocus the light from one focal point to a second without the need for additional focusing components. Learn More

Product	Focal Length	Reflectance	Coating	Availability	Price (USD)
Ellipsoidal Mirror	14 mm (First Focal Length) 134 mm (Second Focal Length)	> 85% (400 - 700 nm, Average)	Protected Aluminum	In stock	$ 365.00
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Diameter 86 mm (Outer) Dimensions Ø 86 x 46 mm Focal Length 14 mm (First Focal Length) 134 mm (Second Focal Length) Substrate Borofloat Hole Diameter 20 mm Height 46 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	13.5 mm (First Focal Length) 120 mm (Second Focal Length)	> 90% (400 - 1500 nm, Average)	Protected Aluminum	6 - 12 weeks	$ 252.00
Product Code Wavelength Range 400 - 1500 nm Reflection Wavelength 400 - 1500 nm Coating Protected Aluminum Reflectance > 90% (400 - 1500 nm, Average) Diameter 76 mm Dimensions Ø 76 mm Thickness 42 mm Focal Length 13.5 mm (First Focal Length) 120 mm (Second Focal Length) Substrate Tempax Hole Diameter 18 mm Weight 100 g Shape Round Type of Curvature Ellipsoidal Supplier Location California, USA See product details More from OptoSigma
Ellipsoidal Mirror	28 mm (First Focal Length) 252 mm (Second Focal Length)	> 90% (400 - 1500 nm, Average)	Protected Aluminum	6 - 12 weeks	$ 525.00
Product Code Wavelength Range 400 - 1500 nm Reflection Wavelength 400 - 1500 nm Coating Protected Aluminum Reflectance > 90% (400 - 1500 nm, Average) Diameter 148 mm Dimensions Ø 148 mm Thickness 63 mm Focal Length 28 mm (First Focal Length) 252 mm (Second Focal Length) Substrate Tempax Hole Diameter 30 mm Weight 190 g Shape Round Type of Curvature Ellipsoidal Supplier Location California, USA See product details More from OptoSigma
Ellipsoidal Mirror	18 mm (First Focal Length) 288 mm (Second Focal Length)	> 90% (400 - 1500 nm, Average)	Protected Aluminum	6 - 12 weeks	$ 394.00
Product Code Wavelength Range 400 - 1500 nm Reflection Wavelength 400 - 1500 nm Coating Protected Aluminum Reflectance > 90% (400 - 1500 nm, Average) Diameter 128 mm Dimensions Ø 128 mm Thickness 67 mm Focal Length 18 mm (First Focal Length) 288 mm (Second Focal Length) Substrate Tempax Hole Diameter 31 mm Weight 160 g Shape Round Type of Curvature Ellipsoidal Supplier Location California, USA See product details More from OptoSigma
Ellipsoidal Mirror	17 mm (First Focal Length) 272 mm (Second Focal Length)	> 90% (400 - 1500 nm, Average)	Protected Aluminum	6 - 12 weeks	$ 315.00
Product Code Wavelength Range 400 - 1500 nm Reflection Wavelength 400 - 1500 nm Coating Protected Aluminum Reflectance > 90% (400 - 1500 nm, Average) Diameter 113 mm Dimensions Ø 113 mm Thickness 54 mm Focal Length 17 mm (First Focal Length) 272 mm (Second Focal Length) Substrate Tempax Hole Diameter 27 mm Weight 150 g Shape Round Type of Curvature Ellipsoidal Supplier Location California, USA See product details More from OptoSigma
Ellipsoidal Mirror	23 mm (First Focal Length) 195 mm (Second Focal Length)	> 90% (400 - 1500 nm, Average)	Protected Aluminum	6 - 12 weeks	$ 394.00
Product Code Wavelength Range 400 - 1500 nm Reflection Wavelength 400 - 1500 nm Coating Protected Aluminum Reflectance > 90% (400 - 1500 nm, Average) Diameter 124 mm Dimensions Ø 124 mm Thickness 56.5 mm Focal Length 23 mm (First Focal Length) 195 mm (Second Focal Length) Substrate Tempax Hole Diameter 25 mm Weight 160 g Shape Round Type of Curvature Ellipsoidal Supplier Location California, USA See product details More from OptoSigma
Ellipsoidal Mirror	22 mm (First Focal Length) 145 mm (Second Focal Length)	> 85% (400 - 700 nm, Average)	Protected Aluminum	In stock	$ 381.00
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Diameter 105 mm (Outer) Dimensions Ø 105 x 44 mm Thickness 44 mm Focal Length 22 mm (First Focal Length) 145 mm (Second Focal Length) Substrate Borofloat Hole Diameter 27 mm Height 44 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	45 mm (±10 mm, First Focal Length) 790 mm (±10 mm, Second Focal Length)	> 85% (400 - 700 nm, Average)	Protected Aluminum	In stock	$ 1290.00
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Diameter 300 mm (Outer) Dimensions Ø 300 x 147 mm Thickness 147 mm Focal Length 45 mm (±10 mm, First Focal Length) 790 mm (±10 mm, Second Focal Length) Substrate Borofloat Hole Diameter 80 mm Height 147 mm Diameter Tolerance +0/-0.5 mm Height Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	22 mm (First Focal Length) 145 mm (Second Focal Length)	> 90% (400 - 1500 nm, Average)	Protected Aluminum	6 - 12 weeks	$ 315.00
Product Code Wavelength Range 400 - 1500 nm Reflection Wavelength 400 - 1500 nm Coating Protected Aluminum Reflectance > 90% (400 - 1500 nm, Average) Diameter 105 mm Dimensions Ø 105 mm Thickness 44 mm Focal Length 22 mm (First Focal Length) 145 mm (Second Focal Length) Substrate Tempax Hole Diameter 27 mm Weight 140 g Shape Round Type of Curvature Ellipsoidal Supplier Location California, USA See product details More from OptoSigma
Ellipsoidal Mirror	14 mm (First Focal Length) 134 mm (Second Focal Length)	> 90% (400 - 1500 nm, Average)	Protected Aluminum	6 - 12 weeks	$ 289.00
Product Code Wavelength Range 400 - 1500 nm Reflection Wavelength 400 - 1500 nm Coating Protected Aluminum Reflectance > 90% (400 - 1500 nm, Average) Diameter 86 mm Dimensions Ø 86 mm Thickness 46 mm Focal Length 14 mm (First Focal Length) 134 mm (Second Focal Length) Substrate Tempax Hole Diameter 20 mm Weight 110 g Shape Round Type of Curvature Ellipsoidal Supplier Location California, USA See product details More from OptoSigma
Ellipsoidal Mirror	11 mm (First Focal Length) 78 mm (Second Focal Length)	> 85% (400 - 700 nm, Average)	Protected Aluminum	In stock	$ 245.00
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Diameter 64 mm (Outer) Dimensions Ø 64 x 44 mm Focal Length 11 mm (First Focal Length) 78 mm (Second Focal Length) Substrate Borofloat Hole Diameter 18 mm Height 44 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	22.5 mm (First Focal Length) 360 mm (Second Focal Length)	> 85% (400 - 700 nm, Average)	Protected Aluminum	In stock	$ 700.00
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Diameter 150 mm (Outer) Dimensions Ø 150 x 70 mm Thickness 70 mm Focal Length 22.5 mm (First Focal Length) 360 mm (Second Focal Length) Substrate Borofloat Hole Diameter 40 mm Height 70 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	11 mm (First Focal Length) 78 mm (Second Focal Length)	> 90% (400 - 1500 nm, Average)	Protected Aluminum	2 weeks	$ 158.00
Product Code Wavelength Range 400 - 1500 nm Reflection Wavelength 400 - 1500 nm Coating Protected Aluminum Reflectance > 90% (400 - 1500 nm, Average) Diameter 64 mm Dimensions Ø 64 mm Thickness 44 mm Focal Length 11 mm (First Focal Length) 78 mm (Second Focal Length) Substrate Tempax Hole Diameter 18 mm Weight 80 g Shape Round Type of Curvature Ellipsoidal Supplier Location California, USA See product details More from OptoSigma
Ellipsoidal Mirror	17 mm (First Focal Length) 272 mm (Second Focal Length)	> 85% (400 - 700 nm, Average)	Protected Aluminum	In stock	$ 408.00
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Diameter 113 mm (Outer) Dimensions Ø 113 x 54 mm Thickness 54 mm Focal Length 17 mm (First Focal Length) 272 mm (Second Focal Length) Substrate Borofloat Hole Diameter 27 mm Height 54 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	40 mm (First Focal Length) 440 mm (Second Focal Length)	> 85% (400 - 700 nm, Average)	Protected Aluminum	Contact Supplier	$ 875.00
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Diameter 220 mm (Outer) Dimensions Ø 220 x 91 mm Thickness 91 mm Focal Length 40 mm (First Focal Length) 440 mm (Second Focal Length) Substrate Borofloat Hole Diameter 60 mm Height 91 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	18 mm (First Focal Length) 288 mm (Second Focal Length)	> 85% (400 - 700 nm, Average)	Protected Aluminum	In stock	$ 488.00
Product Code Wavelength Range 400 - 700 nm Coating Protected Aluminum Reflectance > 85% (400 - 700 nm, Average) Diameter 128 mm (Outer) Dimensions Ø 128 x 67 mm Focal Length 18 mm (First Focal Length) 288 mm (Second Focal Length) Substrate Borofloat Hole Diameter 31 mm Height 67 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	440 mm (Second Focal Length) 40 mm (First Focal Length)	> 97% (450 - 700 nm, Average)	Dielectric	In stock	$ 1290.00
Product Code Wavelength Range 450 - 700 nm Reflection Wavelength 450 - 700 nm Coating Dielectric Reflectance > 97% (450 - 700 nm, Average) Diameter 220 mm (Outer) Dimensions Ø 220 x 91 mm Thickness 91 mm Focal Length 440 mm (Second Focal Length) 40 mm (First Focal Length) Substrate Borofloat Hole Diameter 60 mm Height 91 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	272 mm (Second Focal Length) 17 mm (First Focal Length)	> 97% (450 - 700 nm, Average)	Dielectric	Contact Supplier	$ 540.00
Product Code Wavelength Range 450 - 700 nm Reflection Wavelength 450 - 700 nm Coating Dielectric Reflectance > 97% (450 - 700 nm, Average) Diameter 113 mm (Outer) Dimensions Ø 113 x 54 mm Thickness 54 mm Focal Length 272 mm (Second Focal Length) 17 mm (First Focal Length) Substrate Borofloat Hole Diameter 27 mm Height 54 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	134 mm (Second Focal Length) 14 mm (First Focal Length)	> 97% (450 - 700 nm, Average)	Dielectric	In stock	$ 483.00
Product Code Wavelength Range 450 - 700 nm Reflection Wavelength 450 - 700 nm Coating Dielectric Reflectance > 97% (450 - 700 nm, Average) Diameter 88 mm (Outer) Dimensions Ø 88 x 46 mm Focal Length 134 mm (Second Focal Length) 14 mm (First Focal Length) Substrate Borofloat Hole Diameter 20 mm Height 46 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
Ellipsoidal Mirror	145 mm (Second Focal Length) 22 mm (First Focal Length)	97% (0°, 450 - 700 nm, Average)	Dielectric	In stock	$ 505.00
Product Code Reflection Wavelength 450 - 700 nm Coating Dielectric Reflectance 97% (0°, 450 - 700 nm, Average) Diameter 105 mm (Outer) Dimensions Ø 105 x 42 mm Thickness 42 mm Focal Length 145 mm (Second Focal Length) 22 mm (First Focal Length) Substrate Borofloat Hole Diameter 27 mm Height 42 mm Diameter Tolerance +0/-0.5 mm Shape Round Type of Curvature Ellipsoidal Supplier Location New Jersey, USA See product details More from Edmund Optics
