Polarizing Beamsplitters

Optical components designed for splitting light by polarization state. Learn More

Product	Extinction Ratio	Reflectance	Wavelength Range	Availability	Price (USD)
Polarizing Plate Beamsplitter	10000:1	-	355 nm (Center Wavelength)	In stock	$ 551.20
Product Code Wavelength Range 355 nm (Center Wavelength) Center Wavelength 355 nm Transmittance > 98% (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 6 mm Extinction Ratio 10000:1 Substrate Fused Silica Surface Quality 40-20 scratch-dig Angle of Incidence 45° (±2°) Shape Round Thickness Tolerance ±0.25 mm Clear Aperture 22.5 mm (90%) Transmitted Wavefront Error λ/4 (633 nm, P-V) Supplier Location New Jersey, USA See product details More from Edmund Optics
Polarizing Plate Beamsplitter	> 500:1	< 0.2% (p-pol)	1030 nm	Contact Supplier	$ 385.00
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Reflectance < 0.2% (p-pol) Transmittance < 0.2% (s-pol) Diameter 25.4 mm (1") Dimensions Ø 25.4 mm (1") Thickness 3 mm Parallelism < 30'' Extinction Ratio > 500:1 Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 56° (±2°) Shape Round Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.12 mm Clear Aperture > 21.59 mm Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed > 0.1 J/cm² (50 fs, 50 Hz, 800 nm) Applications Ultrafast Laser Optics Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol)	1030 nm	Contact Supplier	$ 931.52
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) Reflectance > 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol) Dimensions 50 x 20 mm Thickness 6.35 mm (0.25") Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.063; L3x0.004 (Front), 5/2x0.063; L3x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Rectangular Thickness Tolerance ±0.1 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Coating Features Narrowband Chamfer 0.3 mm (Rear) 0.3 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	99.8:1	> 99.8% (45°, 1053 nm, Front) (s-pol) < 1% (45°, 1053 nm, Front) (p-pol)	1053 nm	Contact Supplier	$ 445.31
Product Code Wavelength Range 1053 nm Center Wavelength 1053 nm Coating Reflective V-Coating (1053 nm) AR/Transmissive V-Coating (1053 nm) (Rear) Reflectance > 99.8% (45°, 1053 nm, Front) (s-pol) < 1% (45°, 1053 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 99.8:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 45° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Coating Features Multi Wavelength Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	> 200:1	> 99.5% (s-pol)	800 nm	Contact Supplier	$ 195.00
Product Code Wavelength Range 800 nm Center Wavelength 800 nm Reflectance > 99.5% (s-pol) Transmittance > 95% (p-pol) Diameter 25.4 mm (1") Dimensions Ø 25.4 mm (1") Thickness 3 mm Parallelism < 30'' Extinction Ratio > 200:1 Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 56° (±2°) Shape Round Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.12 mm Clear Aperture > 21.59 mm Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed > 0.1 J/cm² (50 fs, 50 Hz, 800 nm) Applications Ultrafast Laser Optics Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	49.75:1	> 99.5% (56°, 355 nm, Front) (s-pol) < 2% (56°, 355 nm, Front) (p-pol)	355 nm	Contact Supplier	$ 420.32
Product Code Wavelength Range 355 nm Center Wavelength 355 nm Coating Reflective V-Coating (355 nm) Reflectance > 99.5% (56°, 355 nm, Front) (s-pol) < 2% (56°, 355 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 6.35 mm (0.25") Parallelism 5' Extinction Ratio 49.75:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 56° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Nd:YAG Coating Features Narrowband Chamfer 0.3 mm (Rear) 0.3 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (45°, 1030 nm, Front) (s-pol) < 2% (45°, 1030 nm, Front) (p-pol)	1030 nm	In stock	$ 1383.65
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) AR/Transmissive V-Coating (1030 nm) (Rear) Reflectance > 99.9% (45°, 1030 nm, Front) (s-pol) < 2% (45°, 1030 nm, Front) (p-pol) Diameter 50 mm Dimensions Ø 50 mm Thickness 9.5 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/3x0.063; L3x0.004 (Front), 5/3x0.063; L3x0.004 (Rear) (ISO-7) Angle of Incidence 45° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Nd:YAG Coating Features Multi Wavelength Narrowband Chamfer 0.5 mm (Rear) 0.5 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	99.8:1	> 99.8% (56°, 2050 nm, Front) (s-pol) < 1% (56°, 2050 nm, Front) (p-pol)	2050 nm	Contact Supplier	$ 654.34
Product Code Wavelength Range 2050 nm Center Wavelength 2050 nm Coating Reflective V-Coating (2050 nm) Reflectance > 99.8% (56°, 2050 nm, Front) (s-pol) < 1% (56°, 2050 nm, Front) (p-pol) Diameter 25.4 mm (1") Dimensions Ø 25.4 mm (1") Thickness 3 mm Parallelism 5' Extinction Ratio 99.8:1 Substrate Infrasil Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 56° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Ho:YAG Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (45°, 532 nm, Front) (s-pol) < 2% (45°, 532 nm, Front) (p-pol)	532 nm	In stock	$ 259.01
Product Code Wavelength Range 532 nm Center Wavelength 532 nm Coating Reflective V-Coating (532 nm) AR/Transmissive V-Coating (532 nm) (Rear) Reflectance > 99.9% (45°, 532 nm, Front) (s-pol) < 2% (45°, 532 nm, Front) (p-pol) Diameter 12.7 mm (0.5") Dimensions Ø 12.7 mm (0.5") Thickness 3.05 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/1x0.025; L1x0.004 (Front), 5/1x0.025; L1x0.004 (Rear) (ISO-7) Angle of Incidence 45° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Coating Features Multi Wavelength Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	> 200:1	-	1064 nm	Contact Supplier	$ 557.00
Product Code Wavelength Range 1064 nm Center Wavelength 1064 nm Dimensions Ø 50.8 x 6 mm Thickness 6 mm Parallelism < 30'' Extinction Ratio > 200:1 Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 45° (±1°) Shape Round Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.12 mm Clear Aperture > 43.18 x 5.1 mm Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed 10 J/cm² (10 ns, 50 Hz, 1064 nm) Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (45°, 1030 nm, Front) (s-pol) < 2% (45°, 1030 nm, Front) (p-pol)	1020 - 1050 nm 1030 nm	Contact Supplier	$ 462.35
Product Code Wavelength Range 1020 - 1050 nm 1030 nm Center Wavelength 1020 - 1050 nm 1030 nm Coating Reflective V-Coating (1030 nm) BBAR (1020 - 1050 nm) (Rear) Reflectance > 99.9% (45°, 1030 nm, Front) (s-pol) < 2% (45°, 1030 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/3x0.04; L1x0.004 (Front), 5/3x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 45° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Broadband, Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol)	1030 nm	Contact Supplier	$ 420.32
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) Reflectance > 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 2.3 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/1x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Laser Type Yb:YAG Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.05 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	31.67:1	> 95% (60°, 266 nm, Front) (s-pol) < 3% (60°, 266 nm, Front) (p-pol)	266 nm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 266 nm Center Wavelength 266 nm Coating Reflective V-Coating (266 nm) Reflectance > 95% (60°, 266 nm, Front) (s-pol) < 3% (60°, 266 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3 mm Parallelism 5' Extinction Ratio 31.67:1 Substrate UV FS Excimer Grade Surface Quality 10-5 scratch-dig (Output Face) 5/1x0.04; L1x0.004 (Front), 5/1x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 60° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Nd:YAG, Nd:YVO4 Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol)	1030 nm	Contact Supplier	$ 461.22
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) Reflectance > 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 6.35 mm (0.25") Parallelism 30'' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Narrowband Chamfer 0.3 mm (Rear) 0.3 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (56°, 1064 nm, Front) (s-pol) < 2% (56°, 1064 nm, Front) (p-pol)	1064 nm	Contact Supplier	$ 391.92
Product Code Wavelength Range 1064 nm Center Wavelength 1064 nm Coating Reflective V-Coating (1064 nm) Reflectance > 99.9% (56°, 1064 nm, Front) (s-pol) < 2% (56°, 1064 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/3x0.04; L1x0.004 (Front), 5/3x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 56° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Nd:YAG Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	> 200:1	-	255 - 260 nm (Operating Range)	4 - 5 days	$ 633.00
Product Code Wavelength Range 255 - 260 nm (Operating Range) Dimensions 20 x 60 mm Thickness 12 mm Parallelism < 30'' Extinction Ratio > 200:1 Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 70° (±2°) Shape Rectangular Clear Aperture > 17 mm (70°, 85%) Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed 0.05 J/cm² (50 fs, 50 Hz, 800 nm) Applications Ultrafast Laser Optics Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	> 200:1 > 1000:1 (HE Series)	-	1030 nm	4 - 5 days	$ 209.00
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Transmittance > 98% (p-pol) < 0.1% (s-pol) Dimensions 15 x 20 mm Thickness 6 mm Parallelism < 30'' Extinction Ratio > 200:1 > 1000:1 (HE Series) Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 56° (±2°) Shape Rectangular Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.12 mm Clear Aperture > 12.75 x 17 mm (56°) Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed > 0.1 J/cm² (50 fs, 50 Hz, 800 nm) Applications Ultrafast Laser Optics Length 20 mm Width 15 mm Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (56°, 515 nm, Front) (s-pol) < 2% (56°, 515 nm, Front) (p-pol)	515 nm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 515 nm Center Wavelength 515 nm Coating Reflective V-Coating (515 nm) Reflectance > 99.9% (56°, 515 nm, Front) (s-pol) < 2% (56°, 515 nm, Front) (p-pol) Dimensions 30 x 20 mm Thickness 6.35 mm (0.25") Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/4x0.04; L3x0.004 (Front), 5/4x0.04; L3x0.004 (Rear) (ISO-7) Angle of Incidence 56° Shape Rectangular Thickness Tolerance ±0.1 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Narrowband Chamfer 0.3 mm (Rear) 0.3 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	49.9:1	> 99.8% (57°, 1030 nm, Front) (s-pol) < 2% (57°, 1030 nm, Front) (p-pol)	1030 nm	Contact Supplier	$ 420.32
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) Reflectance > 99.8% (57°, 1030 nm, Front) (s-pol) < 2% (57°, 1030 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 49.9:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 57° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	99.9:1	> 99.9% (55°, 2090 nm, Front) (s-pol) < 1% (55°, 2090 nm, Front) (p-pol)	2090 nm	Contact Supplier	$ 277.18
Product Code Wavelength Range 2090 nm Center Wavelength 2090 nm Coating Reflective V-Coating (2090 nm) Reflectance > 99.9% (55°, 2090 nm, Front) (s-pol) < 1% (55°, 2090 nm, Front) (p-pol) Diameter 12.7 mm (0.5") Dimensions Ø 12.7 mm (0.5") Thickness 3 mm Parallelism 5' Extinction Ratio 99.9:1 Substrate Infrasil Surface Quality 10-5 scratch-dig (Output Face) 5/1x0.025 (Front), 5/1x0.025 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Ho:YAG Coating Features Narrowband Supplier Location Germany See product details More from LAYERTEC
