Polarizing Beamsplitters

Optical components designed for splitting light by polarization state. Learn More

Product	Extinction Ratio	Reflectance	Wavelength Range	Availability	Price (USD)
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (55°, 1550 nm, Front) (s-pol) < 2% (55°, 1550 nm, Front) (p-pol)	1550 nm	Contact Supplier	$ 259.01
Product Code Wavelength Range 1550 nm Center Wavelength 1550 nm Coating Reflective V-Coating (1550 nm) Reflectance > 99.9% (55°, 1550 nm, Front) (s-pol) < 2% (55°, 1550 nm, Front) (p-pol) Diameter 12.7 mm (0.5") Dimensions Ø 12.7 mm (0.5") Thickness 3.05 mm Parallelism 10.002'' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/1x0.025; L1x0.004 (Front), 5/1x0.025; L1x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	10000:1	> 99% (s-pol)	532 nm (Center Wavelength)	In stock	$ 523.64
Product Code Wavelength Range 532 nm (Center Wavelength) Center Wavelength 532 nm Reflectance > 99% (s-pol) Transmittance > 98% (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 6 mm Extinction Ratio 10000:1 Substrate Fused Silica Surface Quality 40-20 scratch-dig Angle of Incidence 45° (±2°) Shape Round Thickness Tolerance ±0.25 mm Clear Aperture 22.5 mm (90%) Transmitted Wavefront Error λ/4 (633 nm, P-V) Damage Threshold Pulsed 2 J/cm² (10 ns, 532 nm, P-pol) Supplier Location New Jersey, USA See product details More from Edmund Optics
Polarizing Plate Beamsplitter	49.75:1	> 99.5% (45°, 355 nm, Front) (s-pol) < 2% (45°, 355 nm, Front) (p-pol)	355 nm	In stock	$ 465.76
Product Code Wavelength Range 355 nm Center Wavelength 355 nm Coating Reflective V-Coating (355 nm) AR/Transmissive V-Coating (355 nm) (Rear) Reflectance > 99.5% (45°, 355 nm, Front) (s-pol) < 2% (45°, 355 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 6.35 mm (0.25") Parallelism 5' Extinction Ratio 49.75:1 Substrate UV FS Excimer Grade Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 45° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Nd:YAG Coating Features Multi Wavelength Narrowband Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	> 200:1 > 1000:1 (HE Series)	-	532 nm	Contact Supplier	$ 266.00
Product Code Wavelength Range 532 nm Center Wavelength 532 nm Transmittance > 98% (p-pol) < 0.1% (s-pol) Dimensions 30 x 20 mm Thickness 6 mm Parallelism < 30'' Extinction Ratio > 200:1 > 1000:1 (HE Series) Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 56° (±2°) Shape Rectangular Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.12 mm Clear Aperture > 25.5 x 17 mm (56°) Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed 10 J/cm² (10 ns, 50 Hz, 1064 nm) Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (55°, 750 nm, Front) (s-pol) 2% (55°, 750 nm, Front) (p-pol)	750 nm	In stock	$ 592.99
Product Code Wavelength Range 750 nm Center Wavelength 750 nm Coating Reflective V-Coating (750 nm) Reflectance > 99.9% (55°, 750 nm, Front) (s-pol) 2% (55°, 750 nm, Front) (p-pol) Dimensions 28.6 x 14.3 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Rectangular Thickness Tolerance ±0.1 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Ti:Sa Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol)	1030 nm	Contact Supplier	$ 2385.60
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) Reflectance > 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol) Diameter 70 mm Dimensions Ø 70 mm Thickness 9.5 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/6x0.063; L3x0.004 (Front), 5/6x0.063; L3x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/4 (546.1 nm, Rear) λ/4 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Narrowband Chamfer 0.5 mm (Rear) 0.5 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (56°, 1030 nm, Front) (s-pol) < 2% (56°, 1030 nm, Front) (p-pol)	1030 nm	In stock	$ 391.92
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) Reflectance > 99.9% (56°, 1030 nm, Front) (s-pol) < 2% (56°, 1030 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/3x0.04; L1x0.004 (Front), 5/3x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 56° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	-	< 2% (420 - 670 nm, Front, Absolute)	420 - 700 nm	In stock	$ 258.64
Product Code Wavelength Range 420 - 700 nm Reflectance < 2% (420 - 670 nm, Front, Absolute) Dimensions 25 x 25 mm Thickness 0.7 mm Substrate EAGLE XG Surface Quality 80-50 scratch-dig Angle of Incidence 45° (±15°) Shape Square Thickness Tolerance ±0.07 mm Clear Aperture 21 x 21 mm Operating Temperature -40 to 200 °C Supplier Location New Jersey, USA See product details More from Edmund Optics
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (45°, 1030 nm, Front) (s-pol) < 2% (45°, 1030 nm, Front) (p-pol)	1030 nm	In stock	$ 302.18
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) AR/Transmissive V-Coating (1030 nm) (Rear) Reflectance > 99.9% (45°, 1030 nm, Front) (s-pol) < 2% (45°, 1030 nm, Front) (p-pol) Diameter 12.7 mm (0.5") Dimensions Ø 12.7 mm (0.5") Thickness 3.05 mm Parallelism 10.002'' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/1x0.025; L1x0.004 (Front), 5/1x0.025; L1x0.004 (Rear) (ISO-7) Angle of Incidence 45° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Multi Wavelength Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	> 200:1 > 1000:1 (HE Series)	> 99.5% (s-pol)	532 nm	4 - 5 days	$ 373.00
Product Code Wavelength Range 532 nm Center Wavelength 532 nm Reflectance > 99.5% (s-pol) Transmittance > 95% (p-pol) Diameter 50.8 mm (2") Dimensions Ø 50.8 mm (2") Thickness 6 mm Parallelism < 30'' Extinction Ratio > 200:1 > 1000:1 (HE Series) Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 56° (±2°) Shape Round Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.12 mm Clear Aperture > 43.18 mm Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed 10 J/cm² (10 ns, 50 Hz, 1064 nm) Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	> 200:1	> 99.5% (s-pol)	780 - 820 nm	Contact Supplier	$ 512.00
Product Code Wavelength Range 780 - 820 nm Center Wavelength 780 - 820 nm Reflectance > 99.5% (s-pol) Transmittance > 95% (p-pol) Diameter 50.8 mm (2") Dimensions Ø 50.8 mm (2") Thickness 6 mm Parallelism < 30'' Extinction Ratio > 200:1 Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 56° (±2°) Shape Round Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.12 mm Clear Aperture > 43.18 mm Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed > 0.1 J/cm² (50 fs, 50 Hz, 800 nm) Applications Ultrafast Laser Optics Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	-	97% (55°, 266 nm, Front) (s-pol)	266 nm	Contact Supplier	$ 599.81
Product Code Wavelength Range 266 nm Center Wavelength 266 nm Coating AR/Transmissive V-Coating (266 nm) Reflective V-Coating (266 nm) Reflectance 97% (55°, 266 nm, Front) (s-pol) Transmittance 5% (55°, 266 nm, Front) (p-pol) Diameter 49.5 mm Dimensions Ø 49.5 mm Thickness 2.3 mm Parallelism 5' Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/1x0.025; L1x0.004 (Front), 5/1x0.025; L1x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity 4λ (546 nm, Rear) 4λ (546 nm, Front) Coating Features Multi Wavelength Narrowband Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	> 200:1	-	500 - 530 nm (Operating Range)	4 - 5 days	$ 605.00
Product Code Wavelength Range 500 - 530 nm (Operating Range) Dimensions 20 x 60 mm Thickness 12 mm Parallelism < 30'' Extinction Ratio > 200:1 Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 70° (±2°) Shape Rectangular Clear Aperture > 17 mm (70°, 85%) Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed 0.05 J/cm² (50 fs, 50 Hz, 800 nm) Applications Ultrafast Laser Optics Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	99.8:1	> 99.8% (45°, 1064 nm, Front) (s-pol) < 1% (45°, 1064 nm, Front) (p-pol)	1064 nm	In stock	$ 445.31
Product Code Wavelength Range 1064 nm Center Wavelength 1064 nm Coating Reflective V-Coating (1064 nm) AR/Transmissive V-Coating (1064 nm) (Rear) Reflectance > 99.8% (45°, 1064 nm, Front) (s-pol) < 1% (45°, 1064 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 99.8:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 45° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Coating Features Multi Wavelength Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	99.8:1	> 99.8% (45°, 1040 nm, Front) (s-pol) < 1% (45°, 1040 nm, Front) (p-pol)	1040 nm	Contact Supplier	$ 445.31
Product Code Wavelength Range 1040 nm Center Wavelength 1040 nm Coating Reflective V-Coating (1040 nm) AR/Transmissive V-Coating (1040 nm) (Rear) Reflectance > 99.8% (45°, 1040 nm, Front) (s-pol) < 1% (45°, 1040 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 99.8:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 45° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Nd:YAG Coating Features Multi Wavelength Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	> 200:1	-	1064 nm	4 - 5 days	$ 328.00
Product Code Wavelength Range 1064 nm Center Wavelength 1064 nm Dimensions 35 x 20 x 3 mm Thickness 3 mm Parallelism < 30'' Extinction Ratio > 200:1 Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 56° (±2°) Shape Rectangular Thickness Tolerance ±0.2 mm Diameter Tolerance +0/-0.12 mm Clear Aperture > 29.75 x 17 x 2.55 mm (56°) Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed 10 J/cm² (10 ns, 50 Hz, 1064 nm) Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	49.95:1	> 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol)	1030 nm	In stock	$ 420.32
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) Reflectance > 99.9% (55°, 1030 nm, Front) (s-pol) < 2% (55°, 1030 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Extinction Ratio 49.95:1 Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/1x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Laser Type Yb:YAG Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.05 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	> 200:1	-	980 - 1080 nm (Operating Range)	Contact Supplier	$ 550.00
Product Code Wavelength Range 980 - 1080 nm (Operating Range) Dimensions 20 x 60 mm Thickness 4 mm Parallelism < 30'' Extinction Ratio > 200:1 Substrate UV Fused Silica Surface Quality 20-10 scratch-dig Angle of Incidence 70° (±2°) Shape Rectangular Clear Aperture > 17 mm (70°, 85%) Transmitted Wavefront Error λ/10 (633 nm) Damage Threshold Pulsed 0.05 J/cm² (50 fs, 50 Hz, 800 nm) Applications Ultrafast Laser Optics Supplier Location Lithuania See product details More from EKSMA Optics
Polarizing Plate Beamsplitter	-	> 99.95% (55°, 1030 nm, Front)	1030 nm	Contact Supplier	$ 475.98
Product Code Wavelength Range 1030 nm Center Wavelength 1030 nm Reflection Wavelength 1030 nm Coating Reflective V-Coating (1030 nm) Reflectance > 99.95% (55°, 1030 nm, Front) Diameter 25 mm Dimensions Ø 25 mm Thickness 3.05 mm Parallelism 5' Substrate Fused Silica Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Coating Features Narrowband Chamfer 0.3 mm (Rear) 0.3 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
Polarizing Plate Beamsplitter	99.9:1	> 99.9% (55°, 2090 nm, Front) (s-pol) < 1% (55°, 2090 nm, Front) (p-pol)	2090 nm	In stock	$ 632.75
Product Code Wavelength Range 2090 nm Center Wavelength 2090 nm Coating Reflective V-Coating (2090 nm) Reflectance > 99.9% (55°, 2090 nm, Front) (s-pol) < 1% (55°, 2090 nm, Front) (p-pol) Diameter 25 mm Dimensions Ø 25 mm Thickness 3 mm Parallelism 5' Extinction Ratio 99.9:1 Substrate Fused Quartz Surface Quality 10-5 scratch-dig (Output Face) 5/2x0.04; L1x0.004 (Front), 5/2x0.04; L1x0.004 (Rear) (ISO-7) Angle of Incidence 55° Shape Round Thickness Tolerance ±0.1 mm Diameter Tolerance +0.05/-0.05 mm Surface Irregularity λ/10 (546.1 nm, Rear) λ/10 (546.1 nm, Front) Coating Features Narrowband Chamfer 0.2 mm (Rear) 0.2 mm (Front) Chamfer Tolerance ±0.1 mm Supplier Location Germany See product details More from LAYERTEC
