Polarization Optics

Compare high quality polarization optics from providers around the world, including linear polarizers, polarizing beamsplitters, polarizing prisms, polarization rotators and circular polarizers. Learn More

Product	Extinction Ratio	Reflectance	Wavelength Range	Availability	Price (USD)
Polarizing Cube Beamsplitter	200:1 (Transmission)	> 97% (s-pol)	1064 nm	Contact Supplier	$ 559.00
Product Code Wavelength Range 1064 nm Center Wavelength 1064 nm Coating Dielectric Reflectance > 97% (s-pol) Transmittance > 97% (p-pol) Dimensions 12.7 mm (0.5") Extinction Ratio 200:1 (Transmission) Substrate BK7 Weight 100 g Shape Cube Damage Threshold Pulsed 7 J/cm² Surface Irregularity λ/4 (Flatness) Surface Quality 20-10 scratch-dig Angle of Incidence 0° Length 12.7 mm (0.5") Supplier Location California, USA See product details More from OptoSigma
Half Waveplate	-	-	343 nm	Contact Supplier	$ 998.00
Product Code Wavelength Range 343 nm Coating Dielectric Transmittance > 98% Diameter 25.4 mm (1") Dimensions Ø 25.4 mm (1") Substrate Crystalline Quartz Weight 14.9 g Shape Round Damage Threshold Pulsed 4 J/cm² Surface Irregularity λ/10 (Flatness) Clear Aperture Ø 15 mm Retardance λ/2 Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	500:1 (Transmission)	> 95% (s-pol)	450 - 1080 nm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 450 - 1080 nm Center Wavelength 450 - 1080 nm Coating Dielectric Reflectance > 95% (s-pol) Transmittance > 92% (Average) (p-pol) Dimensions 15 x 15 x 15 mm Extinction Ratio 500:1 (Transmission) Substrate SF15 Weight 9 g Shape Cube Damage Threshold Pulsed 0.3 J/cm² (10 ns, 20 Hz) Surface Irregularity λ/4 (Flatness) Surface Quality 20-10 scratch-dig Angle of Incidence 0° Length 15 mm Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	-	> 97% (s-pol)	1064 nm	Contact Supplier	$ 559.00
Product Code Wavelength Range 1064 nm Center Wavelength 1064 nm Reflectance > 97% (s-pol) Dimensions 10 x 10 x 10 mm Substrate Synthetic Fused Silica Weight 100 g Shape Cube Damage Threshold Pulsed 7 J/cm² Length 10 mm Supplier Location California, USA See product details More from OptoSigma
Half Waveplate	-	-	355 nm	Contact Supplier	$ 798.00
Product Code Wavelength Range 355 nm Coating Dielectric Transmittance > 98.5% Diameter 30 mm Dimensions Ø 30 mm Substrate Crystalline Quartz Weight 8 g Shape Round Damage Threshold Pulsed 1 J/cm² (10 ns, 20 Hz) Surface Irregularity λ/10 (Flatness) Clear Aperture 17 x 17 mm Retardance λ/2 Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	-	-	515 nm (Center Wavelength)	Contact Supplier	$ 559.00
Product Code Wavelength Range 515 nm (Center Wavelength) Center Wavelength 515 nm Dimensions 12.7 mm (0.5") Substrate Synthetic Fused Silica Weight 100 g Shape Cube Length 12.7 mm (0.5") Supplier Location California, USA See product details More from OptoSigma
Half Waveplate	-	-	580 nm	Contact Supplier	$ 280.00
Product Code Wavelength Range 580 nm Diameter 10 mm Dimensions Ø 10 mm Thickness 2.5 mm Substrate Mica Sheet Weight 5 g Shape Round Angle of Incidence 0° Transmitted Wavefront Error 2λ λ (550 nm) Retardance λ/2 Supplier Location California, USA See product details More from OptoSigma
Quarter Waveplate	-	-	1030 nm	Contact Supplier	$ 904.00
Product Code Wavelength Range 1030 nm Coating Dielectric Transmittance > 98% Diameter 25.4 mm (1") Dimensions Ø 25.4 mm (1") Substrate Crystalline Quartz Weight 14.9 g Shape Round Surface Irregularity λ/10 (Flatness) Clear Aperture Ø 15 mm Retardance λ/4 Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	-	> 97% (s-pol)	1064 nm	Contact Supplier	$ 828.00
Product Code Wavelength Range 1064 nm Center Wavelength 1064 nm Reflectance > 97% (s-pol) Dimensions 20 x 20 x 20 mm Substrate Synthetic Fused Silica Weight 100 g Shape Cube Damage Threshold Pulsed 7 J/cm² Length 20 mm Supplier Location California, USA See product details More from OptoSigma
Polarizing Plate Beamsplitter	200:1 (Transmission)	> 95% (s-pol)	266 nm	Contact Supplier	$ 269.00
Product Code Wavelength Range 266 nm Center Wavelength 266 nm Coating Dielectric, Uncoated Reflectance > 95% (s-pol) Transmittance > 92% (p-pol) Diameter 25.4 mm (1") Dimensions Ø 25.4 mm (1") Parallelism < 5'' Extinction Ratio 200:1 (Transmission) Substrate Synthetic Fused Silica Weight 5 g Shape Round Damage Threshold Pulsed 2 J/cm² Surface Irregularity λ/10 (Flatness) Surface Quality 10-5 scratch-dig Angle of Incidence 56.3° Clear Aperture 22.86 mm Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	1000:1 (Transmission)	> 97% (s-pol)	441.6 nm	Contact Supplier	$ 449.00
Product Code Wavelength Range 441.6 nm Center Wavelength 441.6 nm Coating Dielectric Reflectance > 97% (s-pol) Transmittance > 97% (p-pol) Dimensions 20 x 20 x 20 mm Extinction Ratio 1000:1 (Transmission) Substrate BK7 Weight 20 g Shape Cube Damage Threshold Pulsed 0.3 J/cm² (10 ns, 20 Hz) Surface Irregularity λ/4 (Flatness) Surface Quality 20-10 scratch-dig Angle of Incidence 0° Length 20 mm Supplier Location California, USA See product details More from OptoSigma
Quarter Waveplate	-	-	580 nm	Contact Supplier	$ 280.00
Product Code Wavelength Range 580 nm Diameter 10 mm Dimensions Ø 10 mm Thickness 2.5 mm Substrate Mica Sheet Weight 5 g Shape Round Angle of Incidence 0° Transmitted Wavefront Error 2λ λ (550 nm) Retardance λ/4 Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	300:1 (Transmission)	> 95% (s-pol)	1000 - 2000 nm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 1000 - 2000 nm Center Wavelength 1000 - 2000 nm Coating Dielectric Reflectance > 95% (s-pol) Transmittance > 94% (Average) (p-pol) Dimensions 20 x 20 x 20 mm Extinction Ratio 300:1 (Transmission) Substrate SF15 Weight 21 g Shape Cube Damage Threshold Pulsed 0.3 J/cm² (10 ns, 20 Hz) Surface Irregularity λ/4 (Flatness) Surface Quality 20-10 scratch-dig Angle of Incidence 0° Length 20 mm Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	100:1 (Transmission)	> 95% (s-pol)	330 - 370 nm	Contact Supplier	Add to cart to request quote
Product Code Wavelength Range 330 - 370 nm Center Wavelength 330 - 370 nm Coating Dielectric Reflectance > 95% (s-pol) Transmittance > 85% (p-pol) Dimensions 10 x 10 x 10 mm Extinction Ratio 100:1 (Transmission) Substrate Synthetic Fused Silica Weight 5 g Shape Cube Damage Threshold Pulsed 0.3 J/cm² (10 ns, 20 Hz) Surface Irregularity λ/4 (Flatness) Surface Quality 20-10 scratch-dig Angle of Incidence 0° Length 10 mm Supplier Location California, USA See product details More from OptoSigma
Quarter Waveplate	-	-	515 nm	Contact Supplier	$ 904.00
Product Code Wavelength Range 515 nm Coating Dielectric Transmittance > 98% Diameter 25.4 mm (1") Dimensions Ø 25.4 mm (1") Substrate Crystalline Quartz Weight 14.9 g Shape Round Surface Irregularity λ/10 (Flatness) Clear Aperture Ø 15 mm Retardance λ/4 Supplier Location California, USA See product details More from OptoSigma
Half Waveplate	-	-	1064 nm	Contact Supplier	$ 998.00
Product Code Wavelength Range 1064 nm Coating Dielectric Transmittance > 98% Diameter 30 mm Dimensions Ø 30 mm Substrate Crystalline Quartz Weight 15 g Shape Round Surface Irregularity λ/10 (Flatness) Clear Aperture 15 mm Retardance λ/2 Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	1000:1 (Transmission)	> 98% (s-pol)	830 nm	Contact Supplier	$ 315.00
Product Code Wavelength Range 830 nm Center Wavelength 830 nm Coating Dielectric Reflectance > 98% (s-pol) Transmittance > 97% (p-pol) Dimensions 12.7 mm (0.5") Extinction Ratio 1000:1 (Transmission) Substrate BK7 Weight 6 g Shape Cube Damage Threshold Pulsed 0.3 J/cm² (10 ns, 20 Hz) Surface Irregularity λ/4 (Flatness) Surface Quality 20-10 scratch-dig Angle of Incidence 0° Length 12.7 mm (0.5") Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	-	-	343 nm (Center Wavelength)	Contact Supplier	$ 609.00
Product Code Wavelength Range 343 nm (Center Wavelength) Center Wavelength 343 nm Dimensions 12.7 mm (0.5") Substrate Synthetic Fused Silica Weight 100 g Shape Cube Length 12.7 mm (0.5") Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	1000:1 (Transmission)	> 97% (s-pol)	1550 nm	Contact Supplier	$ 299.00
Product Code Wavelength Range 1550 nm Center Wavelength 1550 nm Coating Dielectric Reflectance > 97% (s-pol) Transmittance > 97% (p-pol) Dimensions 5 x 5 x 5 mm Extinction Ratio 1000:1 (Transmission) Substrate BK7 Weight 5 g Shape Cube Damage Threshold Pulsed 0.3 J/cm² (10 ns, 20 Hz) Surface Irregularity λ/4 (Flatness) Surface Quality 20-10 scratch-dig Angle of Incidence 0° Length 5 mm Supplier Location California, USA See product details More from OptoSigma
Polarizing Cube Beamsplitter	1000:1 (Transmission)	> 98% (s-pol)	457.9 nm	Contact Supplier	$ 449.00
Product Code Wavelength Range 457.9 nm Center Wavelength 457.9 nm Coating Dielectric Reflectance > 98% (s-pol) Transmittance > 97% (p-pol) Dimensions 20 x 20 x 20 mm Extinction Ratio 1000:1 (Transmission) Substrate BK7 Weight 20 g Shape Cube Damage Threshold Pulsed 0.3 J/cm² (10 ns, 20 Hz) Surface Irregularity λ/4 (Flatness) Surface Quality 20-10 scratch-dig Angle of Incidence 0° Length 20 mm Supplier Location California, USA See product details More from OptoSigma
