Optomechanics

Optomechanics includes optical mounts, posts, stages, bases, positioners, actuators, and transducers that hold and move optical components and can be assembled to perform a specific function.

Product	Linear Travel	Electrical Capacitance	Dimensions	Availability	Price (USD)
Shear Piezo Transducer	10 μm (Open Loop, X Axis) 10 μm (Open Loop, Y Axis) 10 μm (Open Loop, Z Axis)	160 nF (±32 nF, in Z) 89 nF (±32 nF, in Y) 89 nF (±32 nF, in X)	16 x 16 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 10 μm (Open Loop, X Axis) 10 μm (Open Loop, Y Axis) 10 μm (Open Loop, Z Axis) Electrical Capacitance 160 nF (±32 nF, in Z) 89 nF (±32 nF, in Y) 89 nF (±32 nF, in X) Dimensions 16 x 16 mm Length 40 mm (±0.3 mm) Type of Drive Multilayer Piezo Resonant Frequency 30 kHz (Unloaded) Load Capacity 20 N (Maximum) Type of Movement XYZ Applications Microscopy, Precision Mechanics, Scanning Construction Ceramic Operating Temperature -20 to 85 °C Key Features Open Loop Position Control Open Loop Piezo Material PIC255 Inner Diameter 10 mm Axial Stiffness 120 N/μm Operating Voltage ±250 V Supplier Location Massachusetts, USA See product details More from PI
X/Linear Stage	305 mm (X Axis)	-	-	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 305 mm (X Axis) Type of Drive Ball Screw, Lead Screw, Synchronous Servo Motor Type of Movement X / Linear Construction Aluminum, Stainless Steel Operating Temperature 5 - 40 °C Weight 12.2 kg (Overall) Driving Force 250 N (Peak, Push, in Y) 450 N (Peak, Push, in Z) 700 N (Positive Direction, in X) 700 N (Negative Direction, in X) Travel Resolution 6 μm (Repeatability, Bidirectional, in X) ±10 μm (Accuracy, in X, Uncalibrated) Guide System Ball Bearing Sensor Signal EnDat 2.1, - Flatness ±6 μm Electrical Resistance 5.22 Ω (Typical, Phase-Phase) Electrical Inductance 9.7 mH (Phase-Phase) Platform Size 166 mm Width 166 mm Encoder Resolution 8192 counts/rev Minimum Incremental Movement 2 μm Typical (in X) Moving Mass 2.4 kg (in X) Limit Switches - Velocity 300 mm/s (Maximum, Unloaded, in X) Supplier Location Massachusetts, USA See product details More from PI
Linear Piezo Transducer	2.2 μm	25 nF (±5 nF)	2 x 2 x 2 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 2.2 μm Electrical Capacitance 25 nF (±5 nF) Dimensions 2 x 2 x 2 mm Type of Drive Multilayer Piezo Resonant Frequency > 600 kHz Load Capacity > 120 N Type of Movement X / Linear Applications Life Science Operating Temperature -40 to 150 °C Height 2 mm (±0.1 mm) System of Measurement Metric Operating Voltage -20 to 100 V Supplier Location Massachusetts, USA See product details More from PI
Piezo Bender	200 μm	2 μF, 1.1 μF (±20%)	18 x 9.6 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 200 μm Electrical Capacitance 2 μF, 1.1 μF (±20%) Dimensions 18 x 9.6 mm Length 18 mm (±0.5 mm) 12 mm Type of Drive Multilayer Piezo Resonant Frequency 1.8 kHz (±360 Hz) Load Capacity ±2.1 N Type of Movement X / Linear Construction Ceramic Operating Temperature -20 to 150 °C Width 9.6 mm (±0.2 mm) Height 0.67 mm (±0.1 mm) System of Measurement Metric Operating Voltage 0 - 60 V (±30 V) Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	1 μm (Open Loop, X Axis)	±275 pF (in Z) 2.75 nF (±275 pF, in X)	10 x 10 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 1 μm (Open Loop, X Axis) Electrical Capacitance ±275 pF (in Z) 2.75 nF (±275 pF, in X) Dimensions 10 x 10 mm Length 7.5 mm Type of Drive Multilayer Piezo Load Capacity 150 N (Maximum) Type of Movement X / Linear Applications Scanning Construction Ceramic Operating Temperature -20 to 85 °C Key Features Open Loop System of Measurement Metric Position Control Open Loop Axial Stiffness 900 N/μm Operating Voltage -500 V, 500 V Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	180 μm (Z Axis) 180 μm (Open Loop, Z Axis)	1.5 μF (±300 nF, in Z)	191 x 25 x 25 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 180 μm (Z Axis) 180 μm (Open Loop, Z Axis) Electrical Capacitance 1.5 μF (±300 nF, in Z) Dimensions 191 x 25 x 25 mm Length 191 mm Type of Drive Multilayer Piezo Resonant Frequency 3 kHz (±600 Hz, Unloaded, in Z) Type of Movement Z / Linear Applications Interferometry Precision Mechanics Construction Stainless Steel Operating Temperature -40 to 80 °C Weight 480 g (±24 g, Overall) Driving Force 23 N (Peak, Push, in Y) 4.5 kN (Peak, Push, in Z) 500 N (Peak, Pull, in Z) Travel Resolution 1.8 nm (Open Loop, in Z) 3.6 nm (in Z) Key Features Open Loop Width 25 mm Diameter 10 mm Sensing Technology Strain Gauge Linearity Error 0.2% (Typical, in Z) Height 25 mm Position Control Open Loop Operating Voltage 0 - 1 kV Supplier Location Massachusetts, USA See product details More from PI
X/Linear Stage	200 mm (X Axis)	-	-	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 200 mm (X Axis) Type of Drive Ball Screw, Stepper Motor Type of Movement X / Linear Construction Aluminum, Stainless Steel Operating Temperature 5 - 40 °C Weight 1.16 kg (Overall) Driving Force 50 N (Peak, Push, in Y) 150 N (Peak, Push, in Z) 75 N (in X) Travel Resolution 800 nm (Repeatability, Bidirectional, in X) 80 nm (Resolution, Sensor) ±20 μm (Accuracy, in X, Uncalibrated) Guide System Ball Bearing Sensor Signal A/B quadrature, RS-422, 80 μm Key Features Holding Brake Flatness ±3 μm Type of Encoder Incremental Linear Electrical Resistance 1.18 Ω (Typical, Phase-Phase) Electrical Inductance 0.96 mH (Phase-Phase) Minimum Incremental Movement 0.24 μm Maximum (in X) Moving Mass 140 g (in X) Limit Switches Hall effect, N/C contact, 5 V, NPN Velocity 80 mm/s (Maximum, Unloaded, in X) Operating Voltage 24 - 48 V Acceleration 4 m/s2 Maximum (in X) Power Consumption 8 W (Maximum) Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	3 μm	17 nF	10 x 10 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 3 μm Electrical Capacitance 17 nF Dimensions 10 x 10 mm Length 5.5 mm Type of Drive Multilayer Piezo Resonant Frequency 210 kHz Load Capacity 200 N (Maximum) Type of Movement X / Linear Applications Microscopy, Precision Mechanics, Scanning Axial Stiffness 490 N/μm Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	5 μm	2.5 nF	3 x 3 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 5 μm Electrical Capacitance 2.5 nF Dimensions 3 x 3 mm Length 7.5 mm Type of Drive Multilayer Piezo Resonant Frequency 155 kHz Load Capacity 20 N (Maximum) Type of Movement X / Linear Applications Microscopy, Precision Mechanics, Scanning Axial Stiffness 30 N/μm Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	120 μm	14 μF	116 x 56 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 120 μm Electrical Capacitance 14 μF Dimensions 116 x 56 mm Length 116 mm Type of Drive Multilayer Piezo Resonant Frequency 10 kHz Load Capacity 68 kN Type of Movement X / Linear Applications Precision Mechanics Diameter 56 mm Stiffness 570 N/μm Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	30 μm (Z Axis) 30 μm (Open Loop, Z Axis)	1.1 μF (±220 nF, in Z)	68 x 49.8 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 30 μm (Z Axis) 30 μm (Open Loop, Z Axis) Electrical Capacitance 1.1 μF (±220 nF, in Z) Dimensions 68 x 49.8 mm Length 68 mm Type of Drive Multilayer Piezo Resonant Frequency 10 kHz (±2 kHz, Unloaded, in Z) Type of Movement Z / Linear Applications Interferometry Precision Mechanics Construction Stainless Steel Operating Temperature -40 to 80 °C Weight 690 g (±34.5 g, Overall) Driving Force 420 N (Peak, Push, in Y) 30 kN (Peak, Push, in Z) 3.5 kN (Peak, Pull, in Z) Travel Resolution 300 pm (Open Loop, in Z) 600 pm (in Z) Key Features Vacuum Compatible Diameter 49.8 mm Sensing Technology Strain Gauge Linearity Error 0.2% (Typical, in Z) Operating Voltage 0 - 1 kV Supplier Location Massachusetts, USA See product details More from PI
Stepper Motor Actuator	25 mm (X Axis)	-	115.8 x 39 x 39 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 25 mm (X Axis) Dimensions 115.8 x 39 x 39 mm Length 115.8 mm Type of Drive Lead Screw, Screw, Stepper Motor Type of Movement X / Linear Construction Anodized Aluminum Brass Steel Operating Temperature -20 to 65 °C Weight 610 g (Overall) Driving Force 80 N (in X) Travel Resolution ±2 μm (Repeatability, Unidirectional, in X) 1 μm (Repeatability, Reference Switch) Key Features Limit Switches Width 39 mm Diameter 22 mm Height 39 mm Backlash 10 μm Typical (in X) Minimum Incremental Movement 1 μm Typical (in X) Limit Switches Hall effect Velocity 4 mm/s (Maximum, Unloaded, in X) Operating Voltage 24 V Supplier Location Massachusetts, USA See product details More from PI
Preloaded Piezo Stack Actuator	15 μm (Z Axis)	1.5 μF (±300 nF, in Z)	-	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 15 μm (Z Axis) Electrical Capacitance 1.5 μF (±300 nF, in Z) Length 32 mm (±0.3 mm) Type of Drive Multilayer Piezo Resonant Frequency 18 kHz (±3.6 kHz, Unloaded, in Z) Type of Movement Z / Linear Applications Fiber Positioning Construction Stainless Steel Operating Temperature -20 to 80 °C Weight 20 g (±1 g, Without Cable) Driving Force 1 kN (Peak, Push, in Z) 50 N (Peak, Pull, in Z) Travel Resolution 150 pm (Open Loop, in Z) 300 pm (in Z) Sensing Technology Strain Gauge Supplier Location Massachusetts, USA See product details More from PI
Air Bearing Module	25 mm	-	-	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 25 mm Type of Drive Manual Load Capacity 134 N (Axial) 57 N (Radial) Type of Movement Rotary Applications Metrology, Scanning Construction Hardcoat Aluminum Stainless Steel Mount Weight 400 g (Overall) Sensor Signal Absolute, BiSS-C 32-bit Key Features Air Bearings Flatness 100 nm Platform Size 50 mm Angular Resolution 1.5 nrad (Sensor, Optional) Operating Pressure 75 - 85 psi (515 - 585 kPa) Eccentricity 300 nm Moving Mass 150 g (Rotating) Velocity 3000 rpm (Maximum) 3500 rpm (Maximum, Optional) Air Consumption < 2 SCFM (57 SLPM) Stiffness 26 N/μm (Axial) 8 N/μm (Radial) Angular Wobble 5 μrad Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	30 μm	630 nF	33 x 25 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 30 μm Electrical Capacitance 630 nF Dimensions 33 x 25 mm Length 33 mm Type of Drive Multilayer Piezo Resonant Frequency 35 kHz Load Capacity 12 kN Type of Movement X / Linear Applications Precision Mechanics Diameter 25 mm Stiffness 400 N/μm Supplier Location Massachusetts, USA See product details More from PI
X/Linear Stage	102 mm (X Axis)	-	-	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 102 mm (X Axis) Type of Drive Ball Screw, Brushless DC Motor Type of Movement X / Linear Applications Laser Cutting Construction Aluminum, Stainless Steel Operating Temperature 5 - 40 °C Weight 2.7 kg (Overall) Driving Force 250 N (Peak, Push, in Y) 500 N (Peak, Push, in Z) 500 N (Peak, Push, in X) 100 N (Positive Direction, in X) 250 N (Peak, Pull, in Y) 100 N (Negative Direction, in X) Travel Resolution ±50 nm (Repeatability, Unidirectional, in X) 200 nm (Repeatability, Bidirectional, in X) Guide System Ball Bearing Sensor Signal A/B quadrature, RS-422, Sin/cos, 1 V peak-peak, 20 μm Flatness ±2.5 μm Type of Encoder Incremental Linear Electrical Resistance 810 mΩ (Typical, Phase-Phase) Electrical Inductance 0.64 mH (Phase-Phase) Backlash - Typical (in X) Encoder Resolution 20000 counts/rev Minimum Incremental Movement 0.1 μm Typical (in X) Moving Mass 600 g (in X) Limit Switches Optical Velocity 90 mm/s (Maximum, Unloaded, in X) Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	60 μm	5.7 μF	58 x 40 x 40 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 60 μm Electrical Capacitance 5.7 μF Dimensions 58 x 40 x 40 mm Length 58 mm Type of Drive Multilayer Piezo Resonant Frequency 19 kHz Load Capacity 44 kN Type of Movement X / Linear Applications Precision Mechanics Width 40 mm Diameter 40 mm Stiffness 740 N/μm Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	120 μm	2.6 μF	113 x 25 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 120 μm Electrical Capacitance 2.6 μF Dimensions 113 x 25 mm Length 113 mm Type of Drive Multilayer Piezo Resonant Frequency 10 kHz Load Capacity 14 kN Type of Movement X / Linear Applications Precision Mechanics Diameter 25 mm Stiffness 120 N/μm Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	180 μm	17 μF	154 x 45 x 45 mm	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 180 μm Electrical Capacitance 17 μF Dimensions 154 x 45 x 45 mm Length 154 mm Type of Drive Multilayer Piezo Resonant Frequency 7 kHz Load Capacity 50 kN Type of Movement X / Linear Applications Precision Mechanics Width 45 mm Diameter 45 mm Stiffness 280 N/μm Supplier Location Massachusetts, USA See product details More from PI
Air Bearing Module	65 mm	-	-	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 65 mm Type of Drive Manual Load Capacity 2.144 kN (Axial) 577 N (Radial) Type of Movement Rotary Applications Metrology, Scanning Construction Hardcoat Aluminum Stainless Steel Mount Weight 11.6 kg (Overall) Key Features Air Bearings Flatness 50 nm Platform Size 200 mm Operating Pressure 75 - 85 psi (515 - 585 kPa) Eccentricity 100 nm Moving Mass 4.6 kg (Rotating) Velocity 2000 rpm (Maximum) Air Consumption < 2 SCFM (57 SLPM) Stiffness 385 N/μm (Axial) 110 N/μm (Radial) Angular Wobble 1.5 μrad Supplier Location Massachusetts, USA See product details More from PI
