Optomechanics

Optomechanics includes optical mounts, posts, stages, bases, positioners, actuators, and transducers that hold and move optical components and can be assembled to perform a specific function.

Product	Linear Travel	Electrical Capacitance	Type Of Drive	Availability	Price (USD)
Preloaded Piezo Stack Actuator	15 μm (Open Loop, Z Axis)	1.5 μF (±300 nF, in Z)	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 15 μm (Open Loop, Z Axis) Electrical Capacitance 1.5 μF (±300 nF, in Z) Type of Drive Multilayer Piezo Length 32 mm (±0.3 mm) Type of Movement Z / Linear Resonant Frequency 18 kHz (±3.6 kHz, Unloaded, in Z) Construction Stainless Steel Operating Temperature -20 to 80 °C Weight 20 g (±1 g, Without Cable) Driving Force 1 kN (Peak, Push, in Z) 50 N (Peak, Pull, in Z) Travel Resolution 150 pm (Open Loop, in Z) Applications Fiber Positioning Key Features Open Loop Position Control Open Loop Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	5 μm	28 nF, 47 nF	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 5 μm Electrical Capacitance 28 nF, 47 nF Type of Drive Multilayer Piezo Length 23 mm Type of Movement XYZ Load Capacity 50 N (Maximum) Dimensions 10 x 10 mm Resonant Frequency 50 kHz Applications Microscopy, Precision Mechanics, Scanning Axial Stiffness 120 N/μm Supplier Location Massachusetts, USA See product details More from PI
Mirror Mount	-	-	Slip-Stick Piezo	Contact Supplier	Add to cart to request quote
Product Code Type of Drive Slip-Stick Piezo Type of Movement Tip-Tilt Construction Aluminum, Stainless Steel Operating Temperature 10 - 40 °C Weight 220 g (Overall) Driving Force 22 N (Positive Direction, in Z) Key Features High Stability Vacuum Compatible Holding Force 100 N (Minimum, in Z) Angular Travel 16° (Rotation, in θX) 16° (Rotation, in θY) Type of Optics Circular Size of Compatible Optics Ø 25.4 mm (1") Operating Voltage 80 V Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	3 μm	43 nF	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 3 μm Electrical Capacitance 43 nF Type of Drive Multilayer Piezo Length 9.5 mm Type of Movement XY Load Capacity 300 N (Maximum) Dimensions 16 x 16 mm Resonant Frequency 120 kHz Applications Microscopy, Precision Mechanics, Scanning Axial Stiffness 730 N/μm Supplier Location Massachusetts, USA See product details More from PI
X/Linear Stage	102 mm (X Axis)	-	Ball Screw, Stepper Motor	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 102 mm (X Axis) Type of Drive Ball Screw, Stepper Motor Type of Movement X / Linear Construction Aluminum, Steel Operating Temperature 5 - 40 °C Weight 2.6 kg (Overall) Driving Force 250 N (Peak, Push, in Y) 500 N (Peak, Push, in Z) 100 N (Positive Direction, in X) 250 N (Peak, Pull, in Y) 100 N (Negative Direction, in X) Travel Resolution 5 nm ±50 nm (Repeatability, Unidirectional, in X) 400 nm (Repeatability, Bidirectional, in X) Applications Laser Cutting Guide System Ball Bearing Sensor Signal -, Sin/cos, 1 V peak-peak Flatness ±2.5 μm Type of Encoder Incremental Linear Electrical Resistance 3.3 Ω (Typical, Phase-Phase) Electrical Inductance 2.8 mH (Phase-Phase) Holding Force 50 N (in X) Backlash - Typical (in X) Minimum Incremental Movement 0.02 μm Typical (in X) Moving Mass 600 g (in X) Limit Switches Optical Velocity 45 mm/s (Maximum, Unloaded, in X) Supplier Location Massachusetts, USA See product details More from PI
X/Linear Stage	305 mm (X Axis)	-	Linear Motor	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 305 mm (X Axis) Type of Drive Linear Motor Type of Movement X / Linear Construction Aluminum, Stainless Steel Operating Temperature 5 - 40 °C Weight 7.9 kg (Overall) Driving Force 200 N (Peak, Push, in Y) 400 N (Peak, Push, in Z) 151 N (Peak, in X) 33 N (in X) Travel Resolution 1 μm (Repeatability, Bidirectional, in X) 1 nm (Resolution, Sensor) ±10 μm (Accuracy, in X, Uncalibrated) Guide System Ball Bearing Sensor Signal EnDat 2.2, 0.001 μm Flatness ±6 μm Type of Encoder Absolute, Linear Electrical Resistance 8.96 Ω (Typical, Phase-Phase) Electrical Inductance 1.4 mH (Phase-Phase) Minimum Incremental Movement 0.01 μm Typical (in X) Moving Mass 1.7 kg (in X) Limit Switches - Velocity 2000 mm/s (Maximum, Unloaded, in X) Supplier Location Massachusetts, USA See product details More from PI
Linear XY Stage	350 mm, 500 mm (Gantry Axis) 350 mm, 500 mm (Bridge Axis)	-	Manual	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 350 mm, 500 mm (Gantry Axis) 350 mm, 500 mm (Bridge Axis) Type of Drive Manual Type of Movement XY Load Capacity 147.1 N (15 kg) Driving Force 1 N (Peak) 1 N (Nominal) Travel Resolution ±150 nm (Repeatability, Bidirectional) ±350 nm (Accuracy, Calibrated) 1 nm (Resolution, Sensor) Applications Metrology, SEM, Scanning Guide System Air Bearing Key Features Air Bearings Cleanroom Compatible Flatness 2 μm Type of Encoder Absolute, Linear Electrical Resistance 1 Ω (Phase-Phase) Electrical Inductance 1 mH (Phase-Phase) Orthogonality 1.031'' (5 μrad) Moving Mass 14 kg Velocity 0.5 m/s (Maximum, Unloaded) Acceleration 10 m/s2 (Maximum) Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	3 μm	4.2 nF	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 3 μm Electrical Capacitance 4.2 nF Type of Drive Multilayer Piezo Length 9.5 mm Type of Movement XY Load Capacity 40 N (Maximum) Dimensions 5 x 5 mm Resonant Frequency 120 kHz Applications Microscopy, Precision Mechanics, Scanning Axial Stiffness 70 N/μm Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	10 μm (Open Loop, X Axis)	89 nF (±17.8 nF, in X)	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 10 μm (Open Loop, X Axis) Electrical Capacitance 89 nF (±17.8 nF, in X) Type of Drive Multilayer Piezo Length 12 mm (±0.3 mm) Type of Movement X / Linear Load Capacity 200 N (Maximum) Dimensions 16 x 16 mm Resonant Frequency 100 kHz (Unloaded) Construction Ceramic Operating Temperature -20 to 85 °C Applications Microscopy, Precision Mechanics, Scanning Key Features Open Loop Position Control Open Loop Piezo Material PIC255 Inner Diameter 10 mm Axial Stiffness 400 N/μm Operating Voltage ±250 V Supplier Location Massachusetts, USA See product details More from PI
Patch Piezo Transducer	-	100 nF (±20 nF)	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Electrical Capacitance 100 nF (±20 nF) Type of Drive Multilayer Piezo Type of Movement X / Linear Load Capacity 44 N Dimensions 9.4 x 27 mm Operating Temperature -20 to 150 °C System of Measurement Metric Piezo Material PIC252 Operating Voltage -20 to 120 V Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	8 μm, 6.5 μm	150 nF	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 8 μm, 6.5 μm Electrical Capacitance 150 nF Type of Drive Multilayer Piezo Length 3 mm Type of Movement X / Linear Load Capacity 190 N Dimensions 3 x 2 x 9 mm Resonant Frequency 135 kHz Construction Ceramic Width 2 mm System of Measurement Metric Stiffness 24 N/μm Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	3 μm (Open Loop, X Axis)	6 nF, 250 pF (±20%)	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 3 μm (Open Loop, X Axis) Electrical Capacitance 6 nF, 250 pF (±20%) Type of Drive Multilayer Piezo Length 4.4 mm (±0.3 mm) Type of Movement X / Linear Load Capacity 20 N (Maximum) Dimensions 3 x 3 mm Resonant Frequency 260 kHz (Unloaded) Construction Ceramic Operating Temperature -269 to 85 °C Applications Microscopy, Precision Mechanics, Scanning Key Features Open Loop, Vacuum Compatible Position Control Open Loop Piezo Material PIC255 Axial Stiffness 55 N/μm Operating Voltage ±250 V Supplier Location Massachusetts, USA See product details More from PI
Manual Microscope Stage	25 mm	-	Manual	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 25 mm Type of Drive Manual Type of Movement XY Load Capacity 50 N (Maximum) Dimensions 25 x 25 mm Construction Aluminum, Stainless Steel Weight 4 kg (±200 g) Applications Life Science Key Features High Stability Minimum Incremental Movement 1 μm (Typical) Velocity 1.5 mm/sec (Maximum) Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	10 μm	130 nF	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 10 μm Electrical Capacitance 130 nF Type of Drive Multilayer Piezo Length 12 mm Type of Movement X / Linear Load Capacity 300 N (Maximum) Dimensions 16 x 16 mm Resonant Frequency 100 kHz Applications Microscopy, Precision Mechanics, Scanning Axial Stiffness 580 N/μm Supplier Location Massachusetts, USA See product details More from PI
Piezo Stack Actuator	380 μm (Open Loop, Z Axis) 300 μm (Z Axis)	3.1 μF (±620 nF, in X)	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 380 μm (Open Loop, Z Axis) 300 μm (Z Axis) Electrical Capacitance 3.1 μF (±620 nF, in X) Type of Drive Multilayer Piezo Length 52 mm Type of Movement Z / Linear Dimensions 3.5 x 52 x 5.6 mm Resonant Frequency 110 Hz (±22 Hz, at 180 g, Loaded with 180 g, in Z) 410 Hz (±22 Hz, Unloaded, in Z) Construction Stainless Steel Operating Temperature -20 to 80 °C Weight 40 g (±2 g, Overall) Driving Force 35 N (Peak, Push, in Z) 13 N (Peak, Pull, in Z) Travel Resolution 3 nm (Resolution, Open Loop, in Z) 20 nm (Resolution, in Z) ±10 nm (Repeatability, Unidirectional, in Z) Guide System Flexure Key Features Friction-Free Width 3.5 mm Sensing Technology Strain Gauge Linearity Error 0.2% (Typical, Closed Loop) Height 5.6 mm Supplier Location Massachusetts, USA See product details More from PI
Axial Piezo Transducer	-	70 nF (±14 nF)	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Electrical Capacitance 70 nF (±14 nF) Type of Drive Multilayer Piezo Length 40 mm (±0.2 mm) System of Measurement Metric Piezo Material PIC151 Outer Diameter 40 mm (±0.05 mm) Inner Diameter 38 mm (±0.05 mm) Axial Displacement 15 μm (Maximum) Diameter Displacement 12 μm (Maximum) Operating Voltage 1 kV (Maximum) Supplier Location Massachusetts, USA See product details More from PI
Axial Piezo Transducer	-	12 nF (±2.4 nF)	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Electrical Capacitance 12 nF (±2.4 nF) Type of Drive Multilayer Piezo Length 30 mm (±0.2 mm) System of Measurement Metric Piezo Material PIC151 Outer Diameter 3.2 mm (±0.05 mm) Inner Diameter 2.2 mm (±0.05 mm) Axial Displacement 9 μm (Maximum) Diameter Displacement 900 nm (Maximum) Operating Voltage 500 V (Maximum) Supplier Location Massachusetts, USA See product details More from PI
Piezoelectric Screw Actuator	7 mm (X Axis)	-	Slip-Stick Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 7 mm (X Axis) Type of Drive Slip-Stick Piezo Length 68.6 mm Type of Movement X / Linear Dimensions 68.6 x 27 x 14 mm Construction Aluminum, Stainless Steel Operating Temperature 10 - 40 °C Weight 200 g (Overall) Driving Force 22 N (Peak, Positive Direction, in X) Travel Resolution ±200 nm (Repeatability, Unidirectional, in X) Sensor Signal Sin/cos, 1 V peak-peak Key Features Closed Loop Type of Encoder Angle, Incremental Width 27 mm Holding Force 100 N (Minimum, in X) Linearity Error 0.3% (Typical) Height 14 mm Position Control Closed Loop Minimum Incremental Movement 50 nm Typical (in X) Operating Voltage 80 V Step Frequency 400 Hz (Maximum) 2 kHz (Maximum) Power Consumption 5 W (Maximum) Supplier Location Massachusetts, USA See product details More from PI
Shear Piezo Transducer	3 μm	4.2 nF, 7.3 nF	Multilayer Piezo	Contact Supplier	Add to cart to request quote
Product Code Linear Travel 3 μm Electrical Capacitance 4.2 nF, 7.3 nF Type of Drive Multilayer Piezo Length 15.5 mm Type of Movement XYZ Load Capacity 10 N (Maximum) Dimensions 5 x 5 mm Resonant Frequency 75 kHz Applications Microscopy, Precision Mechanics, Scanning Axial Stiffness 45 N/μm Supplier Location Massachusetts, USA See product details More from PI
Tip-Tilt Platform	±3 mm	-	Manual	Contact Supplier	Add to cart to request quote
Product Code Linear Travel ±3 mm Type of Drive Manual Type of Movement Tip-Tilt Load Capacity 2.144 kN (Maximum, Axial) Weight 8.6 kg (Overall) Travel Resolution 320 μm (per Revolution) Platform Size 200 mm Angular Travel ±1.25° (in θX, in θY) Angular Resolution 1.571 mrad (per Revolution, in θX, in θY) Travel XY-Axis ±3 mm Torque 10 Nm (Maximum) Supplier Location Massachusetts, USA See product details More from PI
